More Adventures in Maintenance - A Summary of the Last 12 Months


at the sunset of our travels ... another maintenance period ...
The saying goes that cruising is maintenance in exotic locations.  There is certainly a lot more to it than, that but the truth is that there is a considerable amount of maintenance to keep any boat - old, new, sail, power - operating.  Add in the fact that we live aboard as a family full time and that we cover a considerable number of miles every year (and it seems like the miles are rarely downwind in the trades) there is lots to keep up with.

We had two main maintenance periods this year: an unplanned but productive one in Fiji, and our recent one here in the Marshall Islands.

The Fiji haulout was precipitated by finding that one of our thru-hulls was ever so slightly weeping.  We were over in the NE side of Fiji in Savusavu preparing to head north to the Marshall Islands so instead we sailed (two days) over to the west side of Fiji to haulout at Vuda Marina.  There we replaced most of the thruhulls that had not been replaced the previous year in New Zealand.  Since we were out of the water anyway, and expecting to cover lots of miles to get to BC, we also redid the anti-fouling and serviced the Maxprop.  We wrote it about is here:  Scheduled Birthday & Unscheduled Haulout

December -  living the glamorous cruising life in the boatyard in Fiji.

The Majuro maintenance period has been focused on preparing the boat for Alaska:

  • Catching up on rebedding deck fittings that have shown any slightest evidence of leaking.  Rebedding involves removing the old, usually metal, fitting from the deck, cleaning all the surfaces, and reinstalling the fitting with fresh adhesive.  This sounds easy, and it normally is, but the complication is that all the fittings are "thru-bolted" so that someone needs to access the nuts on the inside of the boat during the installation and re-installation.  Gaining this access means storage areas need to emptied and cabinetry removed.  You can imagine that this was lots of fun while we were still living onboard!  Often the bolts get mangled in the process, so we replaced most of the fasteners as we went.  I should have bought stock in "Ace Hardware" as I spent a lot of time there buying bolts, washers and nuts.  In fact, it appears that I have bought every 1/4" nut in Majuro!
  • Adding insulation to much of the boat and Hydrovent matting under the mattresses.
  • Adding a heat exchanger to the heater coolant loop so that we can use the engine to heat the boat and make hot water.  Thank you Sure Marine for all the help.  More to follow in a separate blog post on the heater project.
  • Running the heating system to the front of the boat by running another 40' feet of hose and electrical wire, and drilling numerous new holes for them to run through.
  • Ensuring all the preventative maintenance is done to reduce dramas on the long passage north, including doing all the scheduled engine maintenance, even if it is early according to the schedule.
  • Days and days and days of re-stitching seams and sticking patches on our sails
  • Rebuilding our wind generator, whose charge controller died and then caused the rotor to overspeed, melting much of the wiring.  We spent a fortune on a shiny new charge controller that after hours of troubleshooting we found out was defective.  We now are using a simple bridge rectifier to connect our three phase wind generator to the 12 V DC circuit.
  • Troubleshooting, and eventually replacing the solenoid on, our autopilot (including flushing and replacing all the fluid) after it locked up while we were crossing the Majuro lagoon.

It was rather exciting when the autopilot refused to disengage as we arrived into Majuro in January.  We replaced the solenoid and then a few months later it failed again.  Turns out the hydraulic fluid had developed its own ecosystem in the heat despite being less than two years old.  A fun job in Ailuk to flush the system out.  We bought out the entire stock of the appropriate hydraulic fluid that was available in Majuro !

Expanding the heater to the front of the boat.  Another 40' of heater hose installed while we were in Ailuk.

The temporary control panel for the heater system.  The controls are now mounted on a proper panel alongside the Webasto heater controls.
Liz up the mast sewing the leach of the genoa.  After a few hours we realised we needed to drop the sail and do it on deck instead.

Sewing the edge of the genoa back on deck (over a month later when the winds finally dropped).  Johnathan was a big help, and sewing is a great activity for one-on-one conversations!


Liz modeling her new Woolx shirt - and repairing the main.  There wasn't much of a seat close by, so she's perched on a jerry can with a little bit of insulation for a cushion.


Johnathan is quite a competent sail repairer.

Some long days ... using the Speedy Stitcher to repari the bimini.


Victoria adding a Dyneema chafe guard to one of our spinnaker halyards.

It was a whole-crew effort to replace the mast track insert - I went up the mast, Victoria fed it in at the base and Liz & Johnathan operated the winch.  Benjamin supervised himself out of the way.  Thank you Pompanette for the quick work getting us the replacement.


Melted wind generator wires.

Mostly replaced wind generator wiring (although I was not able to get the correct new brushes - I did get shipped the incorrect brush assembly though but that was not much help)

The old wind generator charge controller was likely the cause factor in the demise of the wind generator's wiring so we had a very expensive replacement shipped in.  Mounting it was interesting as it is slightly bigger so we needed to move where two of the solar charge controllers were located.  Then it turned out that the new charge controller was defective so we are just using a simple bridge rectified instead.


And then the rebedding ...  We were suspicious that this window was leaking a bit at sea.  Taking it out took an entire day followed by several days to repair the fiberglass before installing the window again.

Johnathan passing up another window to remount.  The adhesive - 3M 4000UV - gets everywhere.

More rebedding and winch maintenance.

and more rebedding ...

This photo got lots of attention on Facebook as this is how Liz spent Mothers Day.  Rebedding more deck hardware.

Beefing up one of the deck boxes after we found some dry rot.  Nothing a bit of epoxy cannot fix.

Johnathan taking apart the outboard's carburetor.

and servicing his grandmother's old sewing machine.

and Benjamin helping by controlling the reverse switch.
Victoria trying to progress grade 10 while we still have internet despite the chaos around her.

Benjamin too is looking forward to the maintenance period being done.
Somehow despite working pretty relentlessly on this Majuro work period it has taken about six weeks.  That is a lot of rebedding ... It is getting hotter here - it is 30C (86F) by 0900 and the sea temperature is over 30C (86F) so it does not cool off much.

As we have done at regular intervals, please find below an output from our maintenance spreadsheet.  I have cleaned the data up a little and added colour codes showing whether is was an improvement, scheduled or other preventative maintenance or corrective maintenance (i.e. something broke).


Date Item
Category
12-Jun-18 re calibrate speed sensor and heading sensor - old speed 0.95
Electronics
12-Jun-18 compass fluid top up

12-Jun-18 hull/Prop clean - was already clean - light clean on prop Monthly
14-Jun-18 changed autopilot High rudder gain to 1.05
autopilot
16-Jun-18 corrosion control port alternator fuse

17-Jun-18 temp repair to aft injector leak
Engine
20-Jun-18 top up oil - from half on dipstick to full
Engine
20-Jun-18 leaking reefer cooling pump - replaced pump
plumbing
24-Jun-18 fix stbd aft cabin fan wiring
electrical
24-Jun-18 reefer - led's for reefer on, overpressure
electrical
24-Jun-18 check alternator belt tension 50 engine
24-Jun-18 engine air filter check 125 engine
24-Jun-18 check reefer thermostats - fix wiring to freezer thermostat
reefer
25-Jun-18 replace forestay lower cotter pin
Rigging
29-Jun-18 hydrofoil for 20 hp
outboard
29-Jun-18 outboard will not shift. Shifting rod adjusting nut stripped – machined new adjuster nut
outboard
02-Jul-18 adjust dingy hoist bridle
Rigging
04-Jul-18 secure mainsail leech line
sail
06-Jul-18 fix canvas bucket hoop
Sewing
06-Jul-18 reglue to SUP 'D' rings and ctr fin
SUP
10-Jul-18 build emergency kit for dingy - smoke flare, multitool, electrical tape, o rings, pull cord, strobe, whistle, first aid kit

13-Jul-18 hull/Prop clean - still clean Monthly
14-Jul-18 check fuel filter bowls Monthly Engine
14-Jul-18 check Honda outboard raise/lower mechanism
outboard
14-Jul-18 adjust reefer settings to slightly warmer - adjusted to 12F (-11C)
reefer
14-Jul-18 Mainfurl - add wraps
Rigging
14-Jul-18 Prop/shaft zincs - some loss on prop zinc 2 mon
24-Jul-18 2hp outboard stopped - replaced spark plug (BR7HS)
outboard
30-Jul-18 Domestic water pump leaking - replaced pump
plumbing
30-Jul-18 Pressure water filter 4 mon plumbing
30-Jul-18 replace handle for SUP pump
SUP
30-Jul-18 replace feet of swimming ladder

05-Aug-18 Battery water and clean battery top - aft - took 1 L for fwd and port bank. Stbd bank took none 45 days battery water
05-Aug-18 alternator x 3 and starter - check wiring 125 engine
05-Aug-18 check engine mount nuts 250 engine
05-Aug-18 check leak on engine raw water pump ?
Engine
05-Aug-18 engine water strainer 60 days Engine
05-Aug-18 Engine zinc - was maybe ok but replaced 60 days Engine
05-Aug-18 Oil cooler zinc - ok 60 days Engine
05-Aug-18 small leak oil cooler zinc
Engine
05-Aug-18 mainfurl - Grease the grease nipple on the aft end of the spar. 2 Mon Grease
05-Aug-18 Windlass - bimonthly 2 Mon Grease
05-Aug-18 clean reefer strainer and bowl 2 Mon reefer
05-Aug-18 check aft lower deck tie witness marks 12 mon Rigging
05-Aug-18 check furlboom axles
Rigging
11-Aug-18 replace hooks on big lure

12-Aug-18 tighten starter bank alternator
Engine
12-Aug-18 update polars - faster close reaching and slower deep downwind
IT
12-Aug-18 drain outboard carb
outboard
12-Aug-18 anchor shackle - check and replace seizing 3 mon Rigging
13-Aug-18 hull/Prop clean Monthly dive
13-Aug-18 Prop/shaft zincs 2 mon dive
13-Aug-18 check fuel filter bowls Monthly Engine
17-Aug-18 Autopilot - check bolt torque - tightened drive bolts and supports 3 mon autopilot
17-Aug-18 autopilot brush and hyd fluid check 3 mon autopilot
17-Aug-18 bleed heater
heater
17-Aug-18 remove kink in heater hose
heater
17-Aug-18 test Espar heater exhaust and plumbing connections 3 mon heater
17-Aug-18 check and lubricate steering cable 6 mon Lazerrete
17-Aug-18 Steering cable tightness - check quarterly 3 mon Lazerrete
17-Aug-18 reseal leak above furnace and autopilot motor
rebed
17-Aug-18 grease top bearing on rudder post - used corrosion X 3 mon Rigging
17-Aug-18 tighten stbd lower inboard davit bolt

22-Aug-18 find water leak - leaking from saltwater foot pump – closed seacock for water maker
plumbing
22-Aug-18 change speargun line to dynmea
spearfishing
31-Aug-18 Full charge of house bank Monthly battery
05-Sep-18 replace valve on 8m2 kite
kite
10-Sep-18 AIS resets by itself - sprayed plug with 2-26
Electronics
11-Sep-18 check up on outboard ? -cleaned out carb and increased idle speed
outboard
11-Sep-18 outboard tilt mechanism
outboard
11-Sep-18 tighten Honda outboard tiller handle
outboard
12-Sep-18 AIS - test voltage and plugs - all ok
Electronics
12-Sep-18 Oil (100 hrs) - 7.95L of oil 125 engine
12-Sep-18 Oil Filter Change 250 engine
12-Sep-18 Transmission oil change (every 400 hrs or annually) 2.36L 400 engine
13-Sep-18 check alternator belt tension 50 engine
13-Sep-18 Corrosion preventative for ignition key and engine kill knob 6 mon Engine
13-Sep-18 engine water strainer 60 days Engine
13-Sep-18 Engine zinc 60 days Engine
13-Sep-18 Impeller replacement 250 engine
13-Sep-18 Oil cooler zinc 60 days Engine
13-Sep-18 top up coolant - added 0.75 L
Engine
13-Sep-18 clean reefer strainer and bowl 2 Mon reefer
13-Sep-18 shim vang gooseneck
Rigging
14-Sep-18 backup hyd backstay adjuster with dynmea
Rigging
14-Sep-18 inspect lifesling 12 mon Safety
14-Sep-18 vacuum/clean wind gen controller 2 Mon
18-Sep-18 reseal around exhaust flange
rebed
20-Sep-18 #1 alt belt shredding - isolate #1
Engine
20-Sep-18 drain outboard carb Monthly outboard
24-Sep-18 Battery water and clean battery top- fwd - topped up water 90 days battery water
24-Sep-18 leak on stbd aft side of rhib - adhesive added to port and stbd tubes
rhib
24-Sep-18 corrosion control upper deck knives 3 mon Safety
24-Sep-18 check windlass wiring 90 days windlass
27-Sep-18 Replace #2 alternator fuse and clean fuse box
electrical
27-Sep-18 turn fancy not working fan to simple working fan - aft cabin
electrical
27-Sep-18 Replace al#1 belts Gates 9335x2 or Delco 17430
Engine
27-Sep-18 Replace alt2 belts Gates 9335x2 or Delco 17430
Engine
27-Sep-18 Replace mechanical bilge pump belts - Gates 9415
Engine
27-Sep-18 Replace start alt belt Dayco 17520
Engine
27-Sep-18 Windlass - bimonthly 2 Mon Grease
27-Sep-18 Windlass Service - preseason service - every 6 mon 6 mon Grease
27-Sep-18 dingy chaps repair
Sewing
27-Sep-18 check windlass oil level 3 mon windlass
27-Sep-18 check windlass wiring 90 days windlass
27-Sep-18 spray anti-corrosion – windlass motor shaft 12 mon windlass
27-Sep-18 Windlass - gear oil and seal - every 3 years 3 years windlass
28-Sep-18 cover for autopilot motor and espar furnace
Lazerrete
28-Sep-18 Grease autopilot rod end bearing 6 mon lazerrete
28-Sep-18 Grease rudder reference bearing 12 mon Lazerrete
28-Sep-18 inspect shaft seal and rudder boot hose clamps 6 mon lazerrete
28-Sep-18 rudder stops – check and replace rubber 12 mon lazerrete
28-Sep-18 clean watermaker pleated filter 2 Mon watermaker
28-Sep-18 clean watermaker sea strainer 2 Mon watermaker
28-Sep-18 Watermaker carbon filter 6 mon WM
28-Sep-18 Purge fwd water tank with chlorinated water

29-Sep-18 Battery water and clean battery top - aft - 60 days 45 days battery water
29-Sep-18 Check start battery 120 days battery water
29-Sep-18 check fuel filter bowls Monthly Engine
30-Sep-18 chartplotter laggy
Electronics
02-Oct-18 cct panel protectors for cct panel
electrical
02-Oct-18 fan not working on wind gen charge controller - temp fix - added external cooling fan
electrical
02-Oct-18 voltage drop to chartplotter - replaced connections behind wm panel
Electronics
02-Oct-18 ball valve for fresh water foot pump
plumbing
02-Oct-18 leak on fresh water foot pump
plumbing
02-Oct-18 replace salt water foot pump
plumbing
02-Oct-18 test float switch and high water alarm 6 mon plumbing
03-Oct-18 protective sheath around refrigerant lines near thermostats
reefer
03-Oct-18 raise fridge temp slightly - to 30F
reefer
03-Oct-18 knife mount

03-Oct-18 mount vacuum bracket in v berth

04-Oct-18 Full charge of house bank Monthly battery
04-Oct-18 replace switch and wiring to switch
electrical
08-Oct-18 alternator x 3 and starter - check wiring 125 engine
08-Oct-18 check alternator belt tension 125 engine
08-Oct-18 Reefer - return freezer temp to previous setting and fridge to 27
reefer
10-Oct-18 engine water strainer 60 days Engine
10-Oct-18 Engine zinc 60 days Engine
10-Oct-18 Oil cooler zinc 60 days Engine
10-Oct-18 small diesel leak aft injector
Engine
10-Oct-18 tighten alternator belts at 5645
Engine
11-Oct-18 replace start alternator and water pump belt
Engine
15-Oct-18 defrost/clean reefer
reefer
15-Oct-18 reglue rhib stem guard
rhib
15-Oct-18 remove objects in speed sensor

16-Oct-18 tensioner for engine driven bilge pump
Engine
16-Oct-18 test emergency bilge pump 12 mon Safety
17-Oct-18 rain catcher
Sewing
17-Oct-18 replace snap on port rain enclosure strap
Sewing
17-Oct-18 aft hatch support - helicoil

18-Oct-18 covers for exposed screws in propane locker
carpentry
18-Oct-18 Yamaha 2hp - annual service 12 mon outboard
18-Oct-18 icebox drain filter 4 mon plumbing
22-Oct-18 pulpit pedestal

23-Oct-18 repair RED SUP fin
SUP
24-Oct-18 replace alternator belts - large alternators
Engine
24-Oct-18 replace start alternator and water pump belt
Engine
28-Oct-18 Predictwind Iridium Go sim card

01-Nov-18 outboard choke stuck – SE valve removed
outboard
02-Nov-18 tighten alternator belts
Engine
02-Nov-18 Outboard – no cooling water – rerouted hoses
outboard
04-Nov-18 aft head plugged – replaced output hose from toilet to seacock
plumbing
04-Nov-18 replaced aft head intake flapper valve
plumbing
04-Nov-18 replaced aft head joker valve
plumbing
15-Nov-18 cockpit alarm light cover

16-Nov-18 Iridium handheld – GEOS
Electronics
16-Nov-18 Activate new sim card for Iridium Extreme
IT
16-Nov-18 drain outboard carb Monthly outboard
16-Nov-18 Fresh water flush 20 hp outboard
outboard
16-Nov-18 lubricate carb SE valve
outboard
16-Nov-18 prepare 2hp outboard for storage
outboard
16-Nov-18 leak from scupper and sink drain – replace hose
plumbing
16-Nov-18 Flush port scupper

17-Nov-18 check fuel filter bowls Monthly Engine
17-Nov-18 engine air filter check 125 engine
17-Nov-18 check and lubricate deck fill o-rings 6 mon plumbing
17-Nov-18 grease top bearing on rudder post 3 mon Rigging
17-Nov-18 Iridium Extreme – test GEOS
Safety
17-Nov-18 clean watermaker pleated filter 2 Mon watermaker
17-Nov-18 clean watermaker sea strainer 2 Mon watermaker
22-Nov-18 shorten main dingy painter by bridle
Rigging
24-Nov-18 Iridium Extreme does not do SMS
Electronics
24-Nov-18 Iridium Go - GEOS test
Electronics
24-Nov-18 check alternator belt tension 125 engine
24-Nov-18 soft shackle for preventor – one is missing
Rigging
24-Nov-18 bimini - water proofing 6 mon
25-Nov-18 fishing gear – new Halco and rehook squid
fishing
26-Nov-18 Lubricate and inspect steering chain 12 mon binnacle
26-Nov-18 mainfurl - Grease the grease nipple on the aft end of the spar. 2 Mon Grease
26-Nov-18 Windlass - bimonthly 2 Mon Grease
26-Nov-18 check windlass oil level 3 mon windlass
26-Nov-18 top up compass fluid

28-Nov-18 Window gasket – galley

28-Nov-18 Window gasket – saloon stbd fwd

29-Nov-18 install new AP20 display
Electronics
29-Nov-18 configure back up laptop

01-Dec-18 update Predictwind Offshore
IT
02-Dec-18 replace propane solenoid

03-Dec-18 BC servicing
dive
03-Dec-18 regulator freestreams
dive
05-Dec-18 hull/Prop clean Monthly dive
05-Dec-18 Prop/shaft zincs - replace 2 mon dive
05-Dec-18 Fix fan in V berth
electrical
05-Dec-18 install interim propane solenoid switch
electrical
05-Dec-18 engine water strainer 60 days Engine
05-Dec-18 Engine zinc 60 days Engine
05-Dec-18 Oil cooler zinc 60 days Engine
05-Dec-18 Service max prop 12 mon haulout
05-Dec-18 clean reefer strainer and bowl 2 Mon reefer
05-Dec-18 anchor shackle - check and replace seizing 3 mon Rigging
05-Dec-18 MOB light - new D cell x 5 12 mon Safety
05-Dec-18 replace batteries in MOB light
Safety
06-Dec-18 replace bilge pump thru hull
plumbing
06-Dec-18 replace engine thru hull
plumbing
06-Dec-18 check alignment of wind gen blades

06-Dec-18 resilicon instrument panel

07-Dec-18 Antifoul – 2x5L of Hempel paint
haulout
07-Dec-18 propspeed
haulout
07-Dec-18 replace wm thru hull
plumbing
07-Dec-18 clean reefer condenser 12 mon reefer
07-Dec-18 free up traveller block attachments
Rigging
07-Dec-18 windlass cover replacement
Sewing
07-Dec-18 add valve to salt water tap

07-Dec-18 aft burner thermcouple and left fwd burner overflow

07-Dec-18 clean stove orifices

07-Dec-18 resecure stern light pole

08-Dec-18 Full charge of house bank Monthly battery
08-Dec-18 toggle guard on AIS switch
Electronics
08-Dec-18 add shut off valve to fwd head
plumbing
08-Dec-18 aft head overflows from intake
plumbing
08-Dec-18 temp fan for aft cabin

09-Dec-18 Battery water and clean battery top - aft - 60 days 60 days battery water
09-Dec-18 battery equalization 6 mon electrical
09-Dec-18 check alternator belt tension 125 engine
09-Dec-18 engine air filter check 125 engine
09-Dec-18 Honda Outboard - Fuel Filter 12 mon outboard
09-Dec-18 outboard pull cord stuck
outboard
09-Dec-18 clean water tanks – shock treatment – 1L for tank 12 mon plumbing
09-Dec-18 replace drain on rudder post upper bearing housing
plumbing
10-Dec-18 little outboard – water ingress
outboard
11-Dec-18 Pressure water filter 4 mon plumbing
12-Dec-18 check AWA calibration
Electronics
12-Dec-18 Replace HF antenna standoffs
Electronics
12-Dec-18 top up oil
Engine
12-Dec-18 back up stbd spin halyard block
igging
12-Dec-18 Predictwind Tracking
IT
12-Dec-18 Outboard – runs rough and only runs with choke
outboard
12-Dec-18 McLube mast track
Rigging
12-Dec-18 rigging check – up mast
Rigging
12-Dec-18 tighen genoa luff set screw
Rigging
12-Dec-18 Clean/sanitize water jerry cans 6 mon Safety
12-Dec-18 calibrate barometer

13-Dec-18 check compass calibration
Electronics
13-Dec-18 clean bilge

14-Dec-18 Bilge pump float switch us
Safety
16-Dec-18 check Boat Speed calibration 0.95
Electronics
16-Dec-18 drain outboard carb Monthly outboard
16-Dec-18 Label – satphone numbers, cct panel

19-Dec-18 reseat key on aft head handle
plumbing
22-Dec-18 change solar panel settings for hot weather
electrical
22-Dec-18 lower Vcutoff for wind gen charge controller fan
electrical
22-Dec-18 alternator x 3 and starter - check wiring 125 engine
22-Dec-18 check alternator belt tension 125 engine
22-Dec-18 engine air filter check 125 engine
22-Dec-18 chafe on stbd jib sheet
Rigging
22-Dec-18 sew running block cover
Rigging
22-Dec-18 redo solar panel restraining line

22-Dec-18 tighten bilge pump belts

27-Dec-18 change alternator settings for hot weather – bv 14.8 bt 5, av 14.6, at 2, fv 13.5, ffl 30, bdl 5, btemp 43, alt temp 97
electrical
10-Jan-19 Alternator 2 temp sensor
electrical
10-Jan-19 Fuel Filter - Primary 500 engine
10-Jan-19 Fuel Filter - Secondary 500 engine
10-Jan-19 Oil (100 hrs) - 7.95L of oil 125 engine
10-Jan-19 drain outboard carb Monthly outboard
10-Jan-19 chafe on staysail halyard
Rigging
11-Jan-19 aft cabin port fan
electrical
12-Jan-19 propane switch light
electrical
12-Jan-19 Pressure water filter 4 mon plumbing
12-Jan-19 replace domestic pressure water pump
plumbing
12-Jan-19 corrosion control upper deck knives 3 mon Safety
14-Jan-19 clean diesel tanks – aft
Engine
14-Jan-19 clean diesel tanks – ctr
Engine
14-Jan-19 check linkage for extra rode for anchor rode
Rigging
15-Jan-19 stove sparker
electrical
15-Jan-19 repair rot in little cupboard aft cabin port
wood
15-Jan-19 Tippy cupboard – replace hinge
wood
17-Jan-19 renew autopilot computer wiring
Electronics
17-Jan-19 high TDS on watermaker – replace membrane
watermaker
18-Jan-19 chafe material – sensor wires to reefer
electrical
18-Jan-19 Honda outboard - replace carb
outboard
18-Jan-19 Honda outboard – replace choke valve
outboard
18-Jan-19 Reefer – replace water pump with Johnson type CM30-P7-1 Model 102448903 Hose 20mm Flow 22.5 l/m at 15 pka
reefer
18-Jan-19 shorten anchor roller retaining line
Rigging
23-Jan-19 Autopilot – corrosion control
autopilot
23-Jan-19 Autopilot – stuck solenoid ?
autopilot
23-Jan-19 redo rudder stops
Rigging
24-Jan-19 reseal rode hawser hole
Rigging
24-Jan-19 genoa cover repair ripped
Sewing
28-Jan-19 heater does not start – code 25, 37

28-Jan-19 replace dingy anchor chain

29-Jan-19 resecure lazerrete panel screws
carpentry
29-Jan-19 repair to chafe and missing seams on bimini
Rigging
31-Jan-19 inner forestay cotter pins
Rigging
02-Feb-19 repair 8m kite – new bladder
kite
04-Feb-19 inner forestay – add correct cotter pin
Rigging
07-Feb-19 4m kite – leaking spar
kite
07-Feb-19 8m kite – leaking struts x 2
kite
09-Feb-19 fresh water leak ? - fwd shower
plumbing
11-Feb-19 resheave vang dynmea line
Rigging
11-Feb-19 Stbd spin halyard chafe
Rigging
12-Feb-19 engine water strainer 60 days Engine
12-Feb-19 Engine zinc - replaced as fully used up 60 days Engine
12-Feb-19 Oil cooler zinc – replaced zinc as some loss 60 days Engine
12-Feb-19 clean reefer strainer and bowl 2 Mon reefer
12-Feb-19 Mainsail cover out of track
Sewing
14-Feb-19 replace bilge pump panel with 2min alarm
electrical
15-Feb-19 better bilge switch
electrical
17-Feb-19 Battery water and clean battery top - aft – checked only – not filled 60 days battery water
17-Feb-19 service spare outboard carburetor
outboard
17-Feb-19 latch for chart table lid
Safety
17-Feb-19 tears on staysail bag
Sewing
18-Feb-19 mainfurl - Grease the grease nipple on the aft end of the spar. 2 Mon Grease
18-Feb-19 Windlass - bimonthly 2 Mon Grease
18-Feb-19 Steering cable tightness - check quarterly 3 mon Lazerrete
18-Feb-19 reshim gooseneck
Rigging
18-Feb-19 patch dodger aluminum plus rain troughs

19-Feb-19 exhaust elbow – inspect – rusty exterior but not leaking 12 mon Engine
20-Feb-19 Fire detectors
heater
20-Feb-19 8m kite – blown bladder and cover
kite
21-Feb-19 repaint exhaust elbow
Engine
21-Feb-19 touch up engine paint esp transmission port side
Engine
21-Feb-19 Heater will not start – reset water pump
heater
21-Feb-19 chip in bow

23-Feb-19 Autopilot – flush hyd fluid
autopilot
23-Feb-19 Autopilot – stuck briefly with solenoid engaged
autopilot
23-Feb-19 autopilot brush and hyd fluid check 3 mon autopilot
23-Feb-19 test Espar heater exhaust and plumbing connections 3 mon heater
23-Feb-19 4m – replace leaking strut valve
kite
23-Feb-19 8m – strut loses pressure
kite
23-Feb-19 install smoke detector in lazerette
Safety
25-Feb-19 mount for big flashlight
Safety
26-Feb-19 port solar chart controller – shows battery full – replace PCB
electrical
26-Feb-19 Run Webasto Heater 2 Mon heater
26-Feb-19 Honda Outboard - check anodes 6 mon outboard
26-Feb-19 Honda Outboard - grease and corrosion control 6 mon outboard
26-Feb-19 Outboard – stuck in reverse – make new retaining nut
outboard
27-Feb-19 Full charge of house bank Monthly battery
27-Feb-19 hypervent matting under mattresses – aft cabin
Cold Wx
01-Mar-19 hypervent matting under mattresses – bunk cabin
Cold Wx
01-Mar-19 hypervent matting under mattresses – stbd saloon bench
Cold Wx
01-Mar-19 install fan – aft cabin stbd side
electrical
01-Mar-19 8m – replace centre strut nozzle
kite
02-Mar-19 investigate corrosion on fwd port stanchion

04-Mar-19 icebox drain filter 6 mon plumbing
06-Mar-19 fix hinges to fwd port cubby in saloon

08-Mar-19 hypervent matting – port saloon bench
cold Wx
09-Mar-19 Mount thermostats and switches for heaters – saloon
heater
09-Mar-19 drain outboard carb Monthly outboard
10-Mar-19 4m kite – centre strut valve leaking
kite
11-Mar-19 add valve to header tank hose
heater
11-Mar-19 fabricate better route for heater hose below lazerette
heater
11-Mar-19 heater will not start – Espar water pump jammed – removed impellor
heater
11-Mar-19 move and replace thermostat for Webasto heater
heater
12-Mar-19 Mount thermostat and switch for aft cabin
heater
14-Mar-19 Add 3/4” cooling pump to heater and move to aft head
heater
14-Mar-19 add bleeder above hot water tank
heater
16-Mar-19 service old autopilot solenoid
autopilot
16-Mar-19 Battery water and clean battery top - aft – 10 pumps for aft port, 10 stbd aft, 27 fwd batteries 60 days battery water
16-Mar-19 Check start battery 6 mon battery water
16-Mar-19 IS20 Wind at chart table
Electronics
16-Mar-19 tighten start alternator
Engine
16-Mar-19 check stove mount
Safety
16-Mar-19 WM Feedpump#1 not coming up to pressure
wM
20-Mar-19 Full charge of house bank Monthly battery
20-Mar-19 replace lagging on exhaust elbow
Engine
20-Mar-19 measure depth of heater fuel pick up – down to 4 gal therefore approx 45 gal usable from full
heater
20-Mar-19 clean watermaker pleated filter 2 Mon watermaker
20-Mar-19 clean watermaker sea strainer 2 Mon watermaker
25-Mar-19 new hooks for big lure
fishing
25-Mar-19 check outboard oil Monthly outboard
25-Mar-19 Honda outboard - check starter cord 6 mon outboard
25-Mar-19 Honda Outboard - Gear oil 6 mon outboard
25-Mar-19 Honda Outboard - spark plug 6 mon outboard
25-Mar-19 grease top bearing on rudder post 3 mon Rigging
25-Mar-19 New Spinlock PFD - Bobbin TX
Safety
25-Mar-19 chafe in bimini port mid and in front of the rain enclosure both sides
Sewing
26-Mar-19 temp repair fwd hatch bracket
deck
26-Mar-19 Max PFD Knife scabbard – fix
Safety
26-Mar-19 practice rig drogue
Safety
26-Mar-19 test sea anchor plan/check
Safety
27-Mar-19 Battery water and clean battery top- fwd – topped up water 90 days battery water
27-Mar-19 tear in infill – port side plus small holes in UV cover
Sewing
27-Mar-19 check windlass oil level 3 mon windlass
27-Mar-19 check windlass wiring 90 days windlass
29-Mar-19 Reefer – no circulation water
reefer
30-Mar-19 chafe guard for shade cover
Sewing
30-Mar-19 grommet pulling out and loose seam – sun cover
Sewing
01-Apr-19 toilet spring broken
plumbing
01-Apr-19 rebed around the perimeter hatches
rebed
02-Apr-19 rebed around small hatches coamings
rebed
03-Apr-19 replace fwd head window gasket
rebed
03-Apr-19 check and adjust wind gen blade gaps

05-Apr-19 rebed fwd head window
rebed
05-Apr-19 reregister EPRIB/PLB annual Safety
05-Apr-19 fuel consumption data point – fast idle with 150A charge

06-Apr-19 furlboom mast track
Rigging
06-Apr-19 rigging check up mast
Rigging
07-Apr-19 check engine hoses 12 month engine
07-Apr-19 Replace outboard key and corrosion control
outboard
07-Apr-19 replace traveller lines
Rigging
07-Apr-19 CO sensor
Safety
07-Apr-19 test EPIRB annual Safety
08-Apr-19 update/configure US/Canada chart chip
Electronics
09-Apr-19 Engine coolant change 13L 12 mon Engine
10-Apr-19 slight leak from hot water tank output
plumbing
10-Apr-19 increase freezer temp slightly
reefer
10-Apr-19 Watermaker carbon filter 6 mon WM
11-Apr-19 replace barrel bolt in clear companionway cover
deck
11-Apr-19 add thermostat to saloon fan unit
heater
11-Apr-19 engine to heater heat exchanger
heater
11-Apr-19 remount reefer circulation pump to avoid airlock on port tack
reefer
12-Apr-19 fill ding fwd of cockpit stbd

13-Apr-19 add conduit cover to wiring in lazarette
electrical
15-Apr-19 weather station
Electronics
15-Apr-19 engine water strainer 60 days Engine
15-Apr-19 Engine zinc 60 days Engine
15-Apr-19 Oil cooler zinc 60 days Engine
15-Apr-19 replace wiring for saloon aquastat
heater
15-Apr-19 drain outboard carb Monthly outboard
15-Apr-19 move bilge pump switch higher
plumbing
15-Apr-19 HF ant wire - renew - SSB GTO15 connection - battery lug to bulldog clamp. 12 mon Rigging
15-Apr-19 replace mainfurl line with warpspeed
Rigging
15-Apr-19 clean and test bilge float switch 3 mon Safety
15-Apr-19 corrosion control upper deck knives 3 mon Safety
15-Apr-19 test high water alarm 6 mon Safety
17-Apr-19 rebed chart table window
rebed
17-Apr-19 rebed saloon window above barometer
rebed
17-Apr-19 recaulk in front of infill
rebed
17-Apr-19 replace gasket for window over chart table
rebed
19-Apr-19 rebed fwd spin pole bracket
rebed
19-Apr-19 rebed mast collar
rebed
19-Apr-19 rebed spin pole mast block
rebed
19-Apr-19 rebed staysail halyard mast block
rebed
19-Apr-19 rebed v-berth under inner forestay padeye
rebed
22-Apr-19 replace wind generator face bearings
electrical
22-Apr-19 Wind gen – replace burnt wiring
electrical
23-Apr-19 move dodger solar panels to cabinet under chart table seat
electrical
23-Apr-19 Stbd solar charge controller blows fuses – replaced with old slightly defective one
electrical
23-Apr-19 Wind generator – replace charge controller
electrical
24-Apr-19 fix stove sparker
electrical
24-Apr-19 Stove main burner thermocouple
electrical
25-Apr-19 hull/Prop clean Monthly dive
25-Apr-19 replace liferaft tie down
Rigging
25-Apr-19 relash jacklines annual Safety
25-Apr-19 replace jacklines 5 years Safety
25-Apr-19 Overhaul winch - stbd 27 outboard 12 mon winch
27-Apr-19 toilet floods – replace spring
plumbing
28-Apr-19 Impeller replacement 250 engine
29-Apr-19 Rebed and replace hose clamps – aft port outboard scupper
rebed
29-Apr-19 rebed port mid cleat
rebed
29-Apr-19 rebed port padeye near scupper
rebed
29-Apr-19 rebed stanchion outboard port hanging locker
rebed
29-Apr-19 rebed stanchions outboard of port fwd compartment
rebed
02-May-19 replace start battery ?
electrical
02-May-19 rebed port stanchion gate
rebed
03-May-19 insulate saloon top storage
cold Wx
03-May-19 rebed port and stbd genoa track fwd
rebed
03-May-19 rebed toerail outboard of stbd saloon storage
rebed
05-May-19 update chart data – Navionics
Electronics
06-May-19 calibrate barometer
Electronics
06-May-19 Corrosion preventative for ignition key and engine kill knob 6 mon Engine
06-May-19 Insulate heat exchanger
heater
06-May-19 fix cockpit table supports

07-May-19 shackle pin – staysail tack

08-May-19 rebed mid stbd cleat
rebed
08-May-19 rebed stanchion between aft and cap shroud
rebed
08-May-19 rebed toerail outboard of fwd stbd cupboard
rebed
09-May-19 change Webasto fuel filter 12 mon heater
09-May-19 rebed/insulate chart table area
rebed
09-May-19 replace dingy tie down straps
Rigging
09-May-19 rebed genoa track outboard of chart table

09-May-19 rebed stanchion outboard of chart table

09-May-19 rebed toerail outboard of chart table

09-May-19 replace deck box straps

10-May-19 Insulate - Saloon
Cold Wx
10-May-19 replace aft jackline
Safety
12-May-19 aft cabin stanchions and toe rail port side outboard of aft cabin
rebed
12-May-19 rebed aft genoa track stbd
rebed
12-May-19 rebed chimney
rebed
12-May-19 rebed padeye port outboard of dock box
rebed
12-May-19 rebed port genoa foot block
rebed
12-May-19 rebed stanchion and pad eye outboard of stbd deck box
rebed
12-May-19 rebed stanchions stbd aft and toe rail
rebed
12-May-19 rebed stbd genoa foot block
rebed
13-May-19 Mount master controller and pump switch heater – aft cabin
heater
13-May-19 scupper hose clamps – aft cabin stbd hanging locker
plumbing
13-May-19 Insulate/rebed/resecure galley ceiling
rebed
13-May-19 plug wire conduits aft cabin stbd aft
rebed
13-May-19 rebed staysail sheet blocks
rebed
14-May-19 Insulate – aft cabin
cold Wx
14-May-19 insulate heater hose under stbd bench aft cabin and insulate
heater
14-May-19 reconfigure aft cabin air vent – allow full flow
heater
14-May-19 confirm emergency numbers in Satphone - https://sarcontacts.info/ 12 mon Safety
14-May-19 portable watermaker – annual maintenance 12 mon Safety
14-May-19 Replace batteries in electric flare 12 mon Safety
14-May-19 test satphone 12 mon Safety
15-May-19 Fire extinguisher – inspect and service as required 12 mon Safety
15-May-19 temp repair galley fire extinguisher mount
Safety
15-May-19 change solar panel settings for going north

16-May-19 rebed bunk cabin – centre
rebed
16-May-19 rebed handrails – fwd both sides
rebed
16-May-19 rebed life raft cradle
rebed
17-May-19 Insulate – aft head esp behind hot water tank
cold Wx
17-May-19 Insulate – bunk cabin
cold Wx
17-May-19 insulate fwd passageway deckhead
cold Wx
17-May-19 test Espar – white smoke at start
heater
17-May-19 test Espar heater exhaust and plumbing connections 3 mon heater
17-May-19 Pressure water filter 4 mon plumbing
17-May-19 replace rubber pads for liferaft mount
Safety
18-May-19 replace chainplate covers and insulate
cold Wx
18-May-19 alternator x 3 and starter - check wiring 125 engine
18-May-19 check alternator belt tension 125 engine
18-May-19 check engine mount nuts 500 engine
18-May-19 engine air filter check 125 engine
18-May-19 engine water strainer 60 days Engine
18-May-19 reroute engine heater hose to heater heat exchanger
Engine
18-May-19 mainfurl - Grease the grease nipple on the aft end of the spar. 2 Mon Grease
18-May-19 Windlass - bimonthly 2 Mon Grease
18-May-19 Windlass Service - preseason service - every 6 mon 6 mon Grease
18-May-19 BC charts – Coastal Explorer
IT
18-May-19 Inspect lifelines 12 month rigging
18-May-19 chafe protection wm membrane to reefer mount

19-May-19 Cabin sole – locks for main bilge panel
carpenter
19-May-19 Oil (100 hrs) - 7.95L of oil 125 engine
19-May-19 Oil Filter Change 250 engine
19-May-19 fix forward head – new floor bolts, new small bronze bolts for intake and replace valves
plumbing
19-May-19 replace floor pull – fwd passageway

20-May-19 diesel leak – secondary fuel filter
Engine
20-May-19 diesel leak at aft injector
Engine
20-May-19 check mainsail tack and clew lines 12 mon sail
21-May-19 plug for heater exhaust ?
heater
21-May-19 caulk top of all scupper tops
rebed
21-May-19 fwd head – rebed stanchion and pad eye
rebed
21-May-19 rebed electrical fittings under stbd dodger
rebed
21-May-19 rebed fuel and water deck fills into galley
rebed
21-May-19 rebed toerail behind galley drawers x 6 + pad eye
rebed
21-May-19 Genoa inspection 12 mon sail
21-May-19 mainsail inspection 12 mon sail
21-May-19 redo genoa leach repair
sail
21-May-19 leather patch – aft stbd side of bimini
Sewing
21-May-19 replace dripless shaft hose clamps

22-May-19 insulate galley
cold Wx
22-May-19 insulation under heater hoses and behind toilet in aft head
cold Wx
22-May-19 top up oil
Engine
22-May-19 chafe protection – heater hoses by injector pump
heater
22-May-19 staysail inspection 12 mon sail
22-May-19 staysail UV cover loose at one seam and two chafe marks on the luff
sail
23-May-19 Autopilot - check bolt torque 3 mon autopilot
23-May-19 autopilot brush and hyd fluid check 3 mon autopilot
23-May-19 repair stbd dock box
carpentry
23-May-19 add hose insulation – lazerette
heater
23-May-19 Webasto – repair air duct – lazerette
heater
23-May-19 Webasto – repair air intake
heater
23-May-19 check and lubricate steering cable 6 mon Lazerrete
23-May-19 inspect shaft seal and rudder boot hose clamps 6 mon lazerrete
23-May-19 replace or reinforce floor board in lazerrette for autopilot pump – add starboard bar
lazerrete
23-May-19 Steering cable tightness - check quarterly 3 mon Lazerrete
23-May-19 Mainsail – chafe near luff and 5xbatten pockets
sail
23-May-19 Mainsail – damage to leach in one spot and chafe areas
sail
24-May-19 Honda Generator – eco throttle not disengaging
Generator
24-May-19 add fillet to bottom of a/p pump floor
lazerrete
24-May-19 Grease autopilot rod end bearing 6 mon lazerrete
24-May-19 check outboard oil Monthly outboard
24-May-19 drain outboard carb Monthly outboard
24-May-19 JB weld – temp repair to shaft seal

25-May-19 repair aft head floor
carpentry
25-May-19 filter coolant and add filter to header tank
heater
25-May-19 flush heater header tank
heater
25-May-19 Run Webasto Heater 2 Mon heater
25-May-19 renotch mainsail track pins at bottom
Rigging
25-May-19 aft head garbage tie down

25-May-19 webasto fuel filter 12 mon
26-May-19 Honda Outboard - Oil Change 6 mon outboard
26-May-19 grease top bearing on rudder post 3 mon Rigging
26-May-19 temp repair to port handrail
Safety
26-May-19 bimini - water proofing 6 mon
28-May-19 tie down point on inboard side of deck boxes
deck
28-May-19 install wind gen stop switch
electrical
28-May-19 wind gen not braking and spinning freely – replaced controller with bridge rectifier
electrical
28-May-19 replace thermal paste for aft cabin and saloon aquastat
heater
28-May-19 extra sealant around perimeter of windows
rebed
28-May-19 rebed stbd quarter stanchion
rebed
28-May-19 Gluvit aft cabin port fwd cupboard

29-May-19 Battery water and clean battery top - aft - 60 days 60 days battery water
30-May-19 temp repair to deck seams
deck
30-May-19 program Honolulu Sailmail stations
Electronics
30-May-19 Test SSB/Pactor/Sailmail
Electronics
30-May-19 Check drivers for GPS, network, AIS
IT
30-May-19 Outboard SE valve stuck
outboard
30-May-19 redo deck bungs
rebed
30-May-19 tape up dodger panels and running rigging holes
rebed
31-May-19 Dynmea pad eyes for anchor storage in v berth

02-Jun-19 battery equalization and top up water 6 mon electrical
02-Jun-19 Review Ditch Bag contents 12 mon Safety


Happy that this maintenance period is done ...





2 comments:

  1. Hey guys - good luck for the big passage ahead. When do you take off?

    The maintenance spreadsheet put a smile on my face...ahhh the cruising life :)

    Of all the things I have tried over the years to communicate to people the "hard work" of cruising, your spreadsheet does the best job of all. From now on - I am just going to send them a link to your spreadsheet.

    Love the Tika crew!

    ReplyDelete
  2. What a marathon! I was winded just reading about all you have accomplished...

    ReplyDelete

Comments ? (Note all comments are moderated)
